FEEP Technology

Field Emission Electric Propulsion

Best in propulsion

Field Emission Electric Propulsion (FEEP) produces thrust by ions and an applied electrostatic field. By changing the field’s parameters, thrust and specific impulse can be varied as required. In a FEEP thruster, the metal propellant is liquified in orbit, and a strong electrostatic field extracts, ionizes and accelerates the propellant from the ion emitter.

FEEP. Means. Easy and Safe.

The ion emission is supplemented by electron emission from neutralizers to maintain charge stability of the spacecraft. Emitted propellant is replaced in a fully passive manner by capillary forces which maintain propellant supply from the propellant reservoir up to the emitter tips, relying on surface tension of the propellant itself. A FEEP thruster therefore does not require any external forces like pressurization or pumps. Since propellant liquification is only done once in space and for ground vacuum testing, the FEEP system is fully solid and inert during ground handling, integration, and launch.

ENPULSION holds a worldwide exclusive perpetual license to commercialize 30 years of know-how and IPs related to the electric propulsion technology.

Search our knowledge base to learn more about our technology.

Flight Heritage

The ENPULSION NANO Thruster (formerly named ‘IFM Nano’) had its first successful In-Orbit-Demonstration with independently confirmed orbit changes in January 2018. Since then, it has been successfully tested in orbit on multiple customer spacecraft.

Mature Technology

The FEEP technology was developed under ESA contracts for > 15 years. 1,000 + emitters have been tested and an ongoing emitter lifetime test has demonstrated > 30,000 hours of firing without degradation of emitter performance.

Controllable Specific Impulse up to 6,000 s

Due to the efficient process in which up to 60% of the evaporated indium atoms can be ionized, our emitters can provide a very high specific impulse and can accurately control the ISP anywhere from 1,000s to 6,000s.

Debris Safety

Even when active, no part of the thruster is pressurized, and no chemical energy is stored. This means that no explosive reaction can harm the spacecraft system and create additional debris in case of collision.

no propellant containment Issues during launch

Our technology has no moving parts, and the propellant is in solid state during launch. The lack of pressurized tanks and gaseous, liquid, and reactive propellants avoids any risks of propellant containment during launch.

Compact Building Blocks

Our Thruster modules can be used as compact pre-qualified building block in order to provide custom solutions at a commodity price and ultra-short lead times. A whole cluster can be operated as a single plug-and-play unit.

Instantaneous Thrust

FEEP emission is an electrostatic process from a Taylor cone with a ms response time. FEEP Thrusters can enter a hot-standby mode where propellant stays liquified. Response time is then only limited by electronics control.

Dynamic precise thrust Control

Thrust can be controlled through the electrode voltages, providing excellent controllability over the full thrust range down to a precision of a few µN, as well as low thrust noise.

Safe Propellant

Our emitters use indium, a non-toxic, non-reactive and non-radioactive metal as propellant, with negligible evaporation even in vacuum at high temperature.

fast integration & Simple handling

The FEEP thruster technology is an entirely passive system using no hazardous materials and an unpressurized solid propellant during all process stages. Thrusters are delivered in a ready-to-fly state and are designed for simple and fast integration.

Indium – solid metal propellant

Indium, 49In in the periodic table, is used as propellant in our thrusters. It is a very soft, lustrous white metal which was discovered by Ferdinand Reich et al. in 1863. Its name comes from Greek indikón, Latin indicum, as it means indigo blue.

Advantages of indium

  • It is compact due to its higher density — The graph above presents a comparison of tank sizes between the ENPULSION MICRO R³ and a Hall-Effect thruster (operating at 1,200 s ISP @ 100 w) of same total impulse using different propellants.
  • Thrusters are shipped full — Propulsion systems using other propellants usually have to be shipped empty and filled at the launch facility, introducing additional expenses and procedures.
  • It is safe — Indium is non-toxic and easier to handle than other propellants. It is stored unpressurized and, unlike high pressure tanks, it does not need special authorizations (launch waivers) to be launched as secondary payloads, and is RoHS and REACH compliant.
  • It is readily available — Indium is currently a by-product of zinc refining and benefits from industrial scale production. Since peaking at $700 / kg in 2007 indium prices have stayed below $400 / kg.

FEEP technology for a wide range of missions and spacecraft

ENPULSION FEEP Propulsion Systems have been used successfully for:

  • Constellation deployment
  • Station keeping
  • Orbit raising
  • Orbit phasing and Ground Track Improvement
  • Formation Flight
  • Collision avoidance
  • Drag Compensation
  • Small GEO Demo Missions
  • Commercial BIU Missions
  • Several units in space are foreseen to perform de-orbit maneuvers once the first operational missions are over

FMs have also been delivered (but not yet launched) for:

  • SmallSat exploration of the solar system
